Functional characteristics:
- Maximum inlet pressure: 8.6 bar
- Regulator capacity: FE6 6 Stm3/h – FE10 10 Stm3/h – FE25 25 Stm3/h – FES 50 Stm3/h
- Downstream pressure regulation range: BP: 13÷180 mbar; TR: 180÷500 mbar
- Accuracy class AC: up to 5
- Lockup pressure SG: up to 10
- Minimum ambient temperature: Execution up to -40°C
- Maximum ambient temperature: +60°C.
- Gas temperature at inlet: Up to -10°C + 60°C (standard version); -20°C + 60°C (version on request)
- Inlet connection: G ½” ISO 228/1 (modular connections available on request)
- Outlet connection: G 1” ISO 228/1 outlet in line – G ¾” ISO 228/1 angled outlet (modular connections available on request)
Materials:
- Body: Zamak, or aluminum on request
- Covers: Zamak, or aluminum on request
- Diaphragm: Nitrile rubber (TR: linen rubber)
- Seat: Zamak
- O-rings: Nitrile rubber
