Design Features:
Threaded connections: 1” RP ISO, 1” NPT
Flanged connections: Class 150, 300, 600 according to EN1759-1
Materials:
Body: EN AW 6012-T651
Plug: X8CrNiS18-9 EN10088-3 (Aisi303)
+ Nitril Rubber or Viton
Valve seat: X8CrNiS18-9 EN10088-3 (Aisi303)
Operating Features:
- Maximum inlet pressure: 100 bar
- Opening start pressure: ±2%
- Minimum environmental temperature: Up to -20°C
- Maximum environmental temperature: Up to + 60°C
- Inlet gas temperature: Up to -20°C + 60°C
