Construction Features:
- DN calibres available: 25 (1”); 40 (1”1/2)
- Connections: See connections available on configurator
Materials:
- Body: Cast Iron GJS 400–18 UNI EN 1563
Aluminium EN AC 43300 UNI EN 1706
ASTM A 216 WCB (All DNs). - Covers: Aluminium EN AC 43500 UNI EN 1706
- Diaphragm: Fabric Finish Rubber (pre-formed using hot moulding process)
- Seat: Brass / Stainless steel
- O-rings: Nitrile rubber
Operating Features
- Maximum inlet pressure: 10 bar for BP version
20 bar for MP and TR versions - Downstream pressure regulation range: from 15 to 2.500 mbar
- AC accuracy class: up to 5
- SG lock up over pressure: up to 10
- Minimum environmental temperature: Operation up to -40°C (to be specified in the request).
- Maximum environmental temperature: +60°C
- Inlet gas temperature: Up to -20°C +60°C (to be specified in the request).
